Product Name | CIMC brand 3 Axle Low Bed Semi Trailer |
Dimension (mm) | 13,750x3,000x1,800 |
Loading weight (KG) | 55,000 |
Axle | BPW brand, 13T * 3 |
Worktable size (mm) | Approximately 10000 x 3000 x 1080 |
Suspension system | Reverse mechanical suspension 90/10/13 Leaf spring |
Main beam | Beam height 530mm, Top plate18mm, Bottom plate 20mm, Middle plate 12mm. |
Tire | Linglong brand 8.25R20 * 12 pieces |
Central pivot | 3”(90mm) / 2.5”(50mm) |
Worktable thickness | Front 3mm non-slip steel plate, rear 4mm non-slip steel plate |
Ladder | Hydraulic double-section ladder with control box and remote control |
Toolbox | 1 |
Landing gear | Standard 28 tons |
Electrical system | Voltage: 24v Socket: 7-way (7-wire harness) Rear light with indicator, brake light and reflector, side light A standard 6-conductor cable |
Side guard | Standard |
Paint color | Custom (Polyester paint) |
